| Measurement voltage | AC 0 to 2.5 kV, 0 to 5.0 kV, 2 ranges |
|---|---|
| voltage output system | Zero-cross throw switch |
| Setting of voltage | Manual setting by volt slider |
| Accuracy of Voltage | ± 1.5% of F.S. |
| Measurement current | From 0.01 mA to 110.0 mA |
| Accuracy of current | ± ( 5% + 20 μA ) for high setting value |
| Setting time | 0.5 to 999 s (with timer OFF function) |
| judgement of test result | High & low limit |
| Power supply | 90 to 110 V AC, 50/60 HZ (Available 115/200/220/240 V) |
| Weight | Approx. 15 kg (20.5kg for optional power supply) |
| Dimensions | 320 (W) x 150 (H) x 330 (D) mm |
| Accessories | 2 m High-voltage cable, 3 m Earth wire, 2.5 m Power cord, Remote I/O plug, Fuse |
可應用於:
馬達和發電機
火星塞
電容器
連接器
航空組件
變壓器
電線和電纜
線圈和電感
開關和繼電器
