| Measurement voltage | AC 0.2 to 5.00 kV |
|---|---|
| Voltage setting | Digital (setting resolution: 0.01 kV) |
| Waveform, Frequency | Sine wave, 50/60 Hz |
| Measurement current | From 0.01 mA to 20.00 mA |
| Setting time | 0.1 to 99.9 s, 100 to 999 s (with timer OFF function) |
| Measuring voltage | DC 25 V, 50 V, 100 V, 250 V, 500 V, and 1000 V, 6 ranges |
| Measurement range | 0.001 to 9990 MΩ |
| Setting time | 0.2 to 99.9 s (with timer OFF function) |
| Mask time | 0.1 to 99.9 s (Mask time < Setting time) |
| Interface | Remote I/O, RS-232C, USB |
| Power supply | 90 to 250 V AC, 50/60 HZ |
| Weight | Approx. 10 kg |
| Dimensions | 310 (W) x 150 (H) x 380 (D) mm |
| Accessories | 2 m High-voltage cable, 3 m Earth wire, 2.5 m Power cord, Remote I/O plug, Fuse |
可應用於:
馬達和發電機
火星塞
電容器
連接器
航空組件
變壓器
電線和電纜
線圈和電感
開關和繼電器
