預計停止生產，替代型號 3586
| Measurement ranges | 30 mΩ, 300 mΩ, 3, 30, 300, and 3 kΩ, 6 ranges |
|---|---|
| Accuracy |
± 0.5 % of rdg. +8 digit at SLOW sampling mode ± 0.5 % of rdg. +11 digit at MEDIUM sampling mode ± 0.5 % of rdg. +6 digit at FAST sampling mode |
| Measuring frequency | AC1 kHz ± 0.2 Hz |
| Measurement current | From 7.4 mA to 1.5 µA |
| Max. applied voltage | 60V DC for all ranges |
| Sampling time |
50/sec at 50HZ, 60/sec. at 60HZ (FAST mode) 6.25/sec at 50HZ, 7.52/sec. at 60HZ (MEDIUM mode) 1.56/sec at 50HZ, 1.88/sec. at 60HZ (SLOW mode) |
| Response speed |
100 ms at 50HZ, 84 ms at 60 HZ (FAST mode) 800 ms at 50HZ, 667 ms at 60 HZ (MEDIUM mode) 1.92s at 50 HZ, 1.60 ms at 60 HZ (SLOW mode) |
| Measurement method | AC Four-terminal measurement |
| Power supply | 100 to 240 V AC, 50/60 HZ |
| Weight | Approx. 1 kg |
| Dimensions | 206 (W) x 65 (H) x 200 (D) mm |
| Accessories | Power fuse(1), Power cord(1), Input connector (1) |
| Optional accessories |
|
