-電阻測量 3 個量程 30mΩ/300mΩ/3Ω，測量頻率 10kHz
-類比輸出標準設備
-提供多種數據輸出，例如 BCD 和 RS-232C
-可測量一次/二次電池和燃料電池的電阻和電壓
① Data Output
|
Code
|
Description
|
|
356E
|
Without Option
|
|
356E-03
|
With BCD data output (TTL level)
|
|
356E-04
|
With BCD data output (open collector)
|
|
356E-05
|
With RS-232C
|
|
356E-06
|
With RS-485
|
② Judgement Output
|
Code
|
Description
|
|
Nil (blank)
|
Open collector NPN
|
|
RY
|
Relay output
|
Basic Specifications
|
Resistance range
|
30 mΩ, 300 mΩ and 3Ω
|
|
Voltage range
|
DC 5 V and DC 50 V
|
|
Accuracy (representative)
|
Resistance : ± (1.0% of rdg. + 15digit)
Voltage : ± (0.05% of rdg. + 5digit)
|
|
Frequency
|
AC 10 kHz ± 200 Hz
|
|
Measuring Current
|
7.4 mA (for 30 mΩ), 1 mA(for 300 mΩ), 100 μA (for 30Ω)
|
|
Allowable applived voltage
|
DC 60 V for all range
|
|
Sampling rate and Response speed
|
|
SLOW mode:
|
1.56 time/sec. 1.92s for 50 Hz
1.88 time/sec. 1.60s for 60 Hz
|
|
MEDIUM mode:
|
6.25 time/sec. 800ms for 50 Hz
7.52 time/sec. 667ms for 60 Hz
|
|
FAST mode:
|
50 time/sec. 100 ms for 50 Hz
60 time/sec. 84 ms for 60 Hz
|
|
|
Measurement method
|
AC Four-terminal measurement
|
|
Power supply
|
AC100 to 240 V 50/60 Hz
|
|
Weight
|
Approx. 1 kg
|
|
Dimensions
|
206 (W) x 65 (H) x 169 (D) mm
|
|
Optional Accessories
|
 Kelvin clip 5811-24BPower Supply fuse, Power Supply code, Connector for input
|
