| Measurement voltage | AC 0 to 2.5 KV, 0 to 5.0 KV, 2 ranges |
|---|---|
| Accuracy of voltage | ± 1.5 % of F.S. |
| Measurement current | From 0.01 mA to 199.9 mA, 2 ranges |
| Accuracy of current | ± (5% + 20 µA) for high setting value |
| Setting time | 0.5 to 999 s (with timer OFF function) |
| Measuring insulation | DC 500 V and 1000 V, 2 ranges (Available 25/50/100/250 V) |
| Accuracy of insulation |
± 2 % of rdg. +3 digit at 0 to 200.0 MΩ ± 5 % of rdg. +3 digit at 180 to 2000 MΩ |
| Setting time | 0.5 to 999 s (with timer OFF function, Min. mask time +0.2 s) |
| Mask time | 0.3 to 50.0 s (Max. test time –0.2 s) |
| Accuracy of mask time | ± 20 ms up to 99.9 s, ± 200 ms up to 999 s |
| Power supply | 90 to 110 V AC, 50/60 HZ (Available 115/200/220/240 V AC) |
| Weight | Approx. 15 kg (20.5 kg for optional power supply) |
| Dimensions | 320 (W) x 150 (H) x 330 (D) mm |
| Accessories | 2 m High-voltage cable, 3 m Earth wire, 2.5m Power cord, Remote I/O plug, Fuse |
可應用於:
馬達和發電機
火星塞
電容器
連接器
航空組件
變壓器
電線和電纜
線圈和電感
開關和繼電器
